Iron-Doped Magnesium Oxide Thin Films
Iron-Doped Magnesium Oxide Thin Films: Novel Nanomaterials with Optimized Photocatalytic Performance
As the need for environmental pollution control and clean energy development becomes increasingly urgent, photocatalytic technology has emerged as a core technique in environmental remediation due to its advantages of being green, highly efficient, and free from secondary pollution. Metal oxide nanomaterials serve as the fundamental substrates in photocatalysis; among them, magnesium oxide (MgO) stands out as a highly promising candidate due to its unique physicochemical properties. Precise elemental doping can significantly optimize its functional characteristics, thereby greatly enhancing its value for photocatalytic applications.
Magnesium oxide is an ionic crystal material characterized by excellent mechanical strength, corrosion resistance, and chemical stability, alongside being naturally non-toxic and abundant. As a wide-bandgap semiconductor, pure MgO possesses inherent photocatalytic potential—capable of functions such as organic pollutant degradation and carbon dioxide adsorption and conversion—offering broad prospects in environmental remediation and energy conversion. However, pure MgO suffers from limitations such as a narrow photo-response range and a high recombination rate of photogenerated charges, which constrain its actual catalytic efficiency. Consequently, optimizing its structural and optical properties through modification techniques has become a key focus of industry research.
Transition metal doping is an effective method for optimizing metal oxide performance, with iron doping yielding particularly notable results. In this study, ultrasonic spray pyrolysis—a technique offering high industrial compatibility, low cost, and scalability—was employed to fabricate iron-doped MgO thin films with varying doping concentrations on glass substrates. The study systematically investigated the influence of iron content on the material’s structure, morphology, optical properties, and photocatalytic performance, providing a scientific basis for the material’s industrial application.
Crystal structure analysis revealed that all fabricated thin films retained the intact cubic MgO crystal structure; the incorporation of iron did not disrupt the core crystalline framework of the substrate. However, variations in iron doping concentration led to significant changes in the intensity and width of diffraction peaks, directly affecting the film’s crystallinity and grain size, thereby enabling controllable tuning of the material’s microstructure. Microscopic observations reveal that pure magnesium oxide (MgO) films exhibit a surface characterized by tightly packed grains and a regular structure. As the iron doping concentration increases, the surface grains progressively agglomerate and form clusters, leading to a significant rise in surface roughness; this structural transformation directly alters the number of surface active sites.
Regarding optical properties, iron doping causes the optical bandgap of the MgO films to exhibit a non-monotonic trend. Low-level iron doping widens the bandgap, reaching a peak at a doping ratio of 4%, whereas further increases in concentration result in a slight narrowing of the bandgap. This phenomenon arises from the interplay between grain size variations and lattice defects—two competing effects that collectively shape the material’s unique optical characteristics. Furthermore, iron doping introduces specific non-radiative recombination pathways that effectively quench photoluminescence signals and drastically reduce the recombination probability of photogenerated electrons and holes—a critical factor for enhancing photocatalytic efficiency.
The study evaluated the photocatalytic performance of various films by degrading the organic dye methylene blue under ultraviolet light. The results indicate that photocatalytic efficiency does not correlate linearly with iron doping concentration; rather, an optimal doping ratio exists. Specifically, the MgO film with a low iron doping concentration of 0.5% demonstrated the best performance, achieving a dye degradation efficiency of 87.19% and a catalytic reaction rate far exceeding that of pure MgO films. Conversely, at excessively high doping concentrations, severe grain agglomeration on the film surface significantly reduces the number of catalytically active sites; simultaneously, an excess of defects acts as charge recombination centers, thereby inhibiting photocatalytic efficiency.
This research confirms that controlled, low-level iron doping allows for the precise tuning of the microstructure and optical properties of MgO films. Iron serves a dual purpose: it introduces intermediate energy levels within the band structure—thereby broadening the photo-response range and promoting charge separation—while also optimizing the catalytic reaction interface by modulating surface morphology. Ultrasonic spray pyrolysis enables the stable fabrication of high-performance doped films, making the process suitable for large-scale production. This study elucidates the intrinsic relationships among doping concentration, microstructure, and catalytic performance, offering a new approach to the modification and optimization of wide-bandgap oxide materials and providing high-quality, novel functional materials for environmental remediation applications such as water pollution control and the degradation of organic pollutants.
